Sealed Lead Acid Battery

Maintenance-free
no water adding required
Sealed Valve-regulate
Spill proof and leak proof

Inquiry now
Overview
    Maintenance-free, no water adding required; Sealed Valve-regulated, Spill proof and leak proof.
Feature
    1.Using oxygen recombination technology: maintenance-free
    2.PbCaSn alloy for plate grids: less gassing, less self-discharging
    3.High quality AGM separator: extend cycle life and prevent micro short circuit
    4.ABS material: increase the strength of battery container. (Flame-retardant ABS is optional);
    5.High purity raw material: ensure low self discharge rate
    6.Silver-coated copper terminals (T1, T2 terminal), brass insert terminals and lead terminals improve the electric conductivity
Application
UPS system, storage system, and any other services need uninterruptible DC power.
Related Products
    >> Lead Carbon Battery
    >> Lithium Battery
    >> Battery Management System
Related Solution
    >> ESS & Battery Solution

Model Rated voltage (V) Rated capacity(Ah) Dimension (mm) Weight(Kg) Terminals
1.80V 1.75V 1.75V 1.67V length width height total height
20HR 10HR 5HR 1HR (L) (W) (H) (H)
DJW12-0.8 12 0.8 0.72 0.7 0.5 96.0±1 25.0±1 62.0±1 62.0±1 0.34 /
DJW12-1.2 12 1.4 1.3 1.2 0.85 97.0±1 43.0±1 52.0±1 58.0±1 0.57 T1
DJW12-1.9 12 1.9 1.78 1.6 1.2 178.0±1 35.0±1 60.0±1 66.0±1 0.93 T1
DJW12-2.0NP 12 2 1.9 1.7 1.24 151.0±1 20.0±1 89.0±1 89.0±1 0.68 /
DJW12-2.0C1 12 2 1.9 1.7 1.24 143.0±1 24.0±1 65.0±1 65.0±1 0.57 /
DJW12-2.3 12 2.5 2.3 2 1.5 178.0±1 35.0±1 60.0±1 66.0±1 1 T1
DJW12-2.3C 12 2.3 2.1 1.95 1.43 182.0±1 24.0±1 61.0±1 61.0±1 0.7 /
DJW12-2.6 12 2.6 2.3 2.11 1.56 70.0±1 48.0±1 98.0±1 104.0±1 0.8 T1
DJW12-2.8 12 2.8 2.5 2.29 1.68 132.0±1 33.0±1 98.0±1 104.0±1 1.18 T1
DJW12-2.9 12 3 2.7 2.45 1.8 178.0±1 35.0±1 60.5±1 66.0±1 1.1 T1
DJW12-3.0 12 3 2.8 2.55 1.86 141.0±1 33.0±1 102.0±1 108.0±1 1.2 T1
DJW12-3.2 12 3.5 3.3 3 2.17 134.0±1 67.0±1 60.5±1 66.5±1 1.35 T1
DJW12-4.0 12 4 3.7 3.4 2.48 90.0±1 70.0±1 101.0±1 107.0±1 1.48 T1
DJW12-4.5 12 4.6 4.1 3.7 2.85 90.0±1 70.0±1 101.0±1 107.0±1 1.6 T1
DJW12-5.0 12 5 4.5 4.2 3.1 151.0±1 53.0±1 93.0±1 99.0±1 1.9 T1/T2
DJW12-6.0 12 6 5.6 5.1 3.72 90.0±1 70.0±1 101.0±1 107.0±1 1.8 T1/T2
DJW12-7.0 12 7 6.3 5.5 4.34 151.0±1 65.0±1 94.0±1 100.0±1 2.2 T1/T2
DJW12-7.2 12 7.2 6.69 6.12 4.46 151.0±1 65.0±1 94.0±1 100.0±1 2.2 T1/T2
DJW12-7.5 12 7.5 6.97 6.38 4.65 151.0±1 65.0±1 94.0±1 100.0±1 2.54 T1/T2
DJW12-7.8 12 7.8 7.25 6.63 4.83 151.0±1 65.0±1 94.0±1 100.0±1 2.54 T1/T2
DJW12-8.5 12 8.5 7.91 7.23 5.27 151.0±1 65.0±1 94.5±1 100.0±1 2.75 T1/T2
DJW12-10 12 10 9.3 8.5 6.2 151.0±1 98.0±1 95.0±1 101.0±1 3.26 T2/T1
DJW12-10H 12 10 9.3 8.5 6.2 151.0±1 65.0±1 111.0±1 117.0±1 3.2 T2/T1
DJW12-12 12 12 11.1 10.35 7.24 151.0±1 98.0±1 95.0±1 101.0±1 3.56 T2/T1
DJW12-14 12 14 13 12.05 8.45 151.0±1 98.0±1 95.0±1 101.0±1 4.2 T2/T1
DJW12-18 12 18 17 16 11.1 181.5±1 77.0±1 167.5±1 167.5±1 5.32 T3/T12
DJW12-20 12 20 18.6 17 12.4 181.5±1 77.0±1 167.5±1 167.5±1 5.58 T3/T12
DJW12-24 12 24 22.3 20.4 14.88 165.5±1 176.0±1 125.0±1 125.0±1 8.1 T3/T12
DJW12-26 12 26 24.18 22.1 16.12 166.5±1 175.0±1 125.0±1 125.0±1 8.35 T3/T12
DJW12-28 12 28 26 23.8 17.4 176.0±1 166.5±1 125.0±1 125.0±1 8.8 T3/T12
DJW12-35 12 35 33 30.5 21.45 195.0±1 130.0±1 164.0±1 180.0±1 11.2 T5/T6/T12/T10
